U859QL

Brand: Audio Technica

$149.00

U859ql Cardioid Condenser 11-52V Phantom Power Only,Integral Power Module W/ XLRM Type Connector Plugs Directly Into An XLRF Type Panel Mount

SKU: U859QL Category:

Manufacturer’s website



Designed to plug directly into panel- or desk-mounted XLRF-type connector, the U859QL features an ultra-flexible small-diameter gooseneck and accepts interchangeable elements, available in cardioid, hypercardioid, omnidirectional and UniLine line cardioid polar patterns. Equipped with self-contained electronics, the phantom-powered microphone also offers an 80 Hz low-cut UniSteep filter that reduces pickup of low-frequency ambient noise. The microphone is 18.90 in long.



    – Designed for high-quality sound reinforcement, professional recording and broadcasting
    – Superior off-axis rejection for maximum gain before feedback
    – Easy-to-adjust, rugged, small-diameter, alternating gooseneck with virtually no inmemory in permits quick positioning into desired shape
    – UniSteep filter provides steep low-frequency attenuation to improve sound pickup without affecting voice quality
    – Self-contained electronics eliminate need for external power module
    – Quick-mount design with 3-pin XLRM-type connector insert at base plugs into any standard XLRF-type surface or cable connector




























































































SPECIFICATIONS

ELEMENT Fixed-charge back plate permanently polarized condenser



POLAR PATTERN Cardioid



FREQUENCY RESPONSE 100-16,000 Hz



LOW FREQUENCY ROLL-OFF 80 Hz, 18 dB/octave



OPEN CIRCUIT SENSITIVITY 43 dB (7.0 mV) re 1V at Pa



IMPEDANCE 250 ohms



MAXIMUM INPUT SOUND LEVEL 140 dB SPL, kHz at percent T.H.D.



DYNAMIC RANGE (typical) 111 dB, kHz at Max SPL



SIGNAL-TO-NOISE RATIO 65 dB, kHz at Pa



PHANTOM POWER REQUIREMENTS 11-52V DC, mA typical



SWITCH Flat, roll-off



WEIGHT 5.4 oz (152 g)



DIMENSIONS 18.90 in (480.0 mm) long,
0.48 in (12.3 mm) head diameter,
0.74 in (18.9 mm) base diameter



OUTPUT CONNECTOR Integral 3-pin XLRM-type



ACCESSORY FURNISHED AT8153 two-stage foam windscreen



AUDIO-TECHNICA CASE STYLE M34

























SPECIFICATION GRAPHS

Click on the chart to view the larger image
POLAR PATTERN POLAR PATTERN
FREQUENCY RESPONSE FREQUENCY RESPONSE
